Product Description
Pad Mounted Transformers are suitable for commercial centers, industrial parks, residential quarters, streets, airports, docks, subways and other urban densely populated areas, and can also be used in mines, and deep into the load center for ring network and bidirectional power supply.
Product Description
Our pad mounted transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time.
We ensure that each one of our delivered units has undergone rigorous full acceptance testing. We provide one-package service from consulting, quoting, manufacturing, installation, commissioning, training to after sale services, our products are now operating in more than 50 counties in the world. We aim to be your most reliable supplier as well as your best partner in business!
Product Parameters
Rated Capacity (KVA) | High Voltage (KV) | Low Voltage (V) | Tapping Range& Vector symbol | Loss(W) | |
No-load | On-load | ||||
30 | 6.3 7.2 7.62 8.6 12.47 13.2 13.8 19.8 19.92 23 34.5 35 To be requested by customers | 110 220 230 240 347 480 277 600 | ±5 (±2*2.5) Yyn0 Dyn11 | 110 | 500 |
63 | 200 | 1040 | |||
75 | 180 | 1250 | |||
125 | 220 | 1700 | |||
150 | 280 | 2200 | |||
225 | 400 | 3050 | |||
300 | 480 | 3650 | |||
500 | 680 | 5100 | |||
750 | 980 | 7500 | |||
1000 | 1150 | 10300 | |||
1500 | 1640 | 14500 | |||
2000 | 2160 | 20645 | |||
2500 | 2680 | 27786 | |||
3000 | 3300 | 30300 | |||
3750 | 4125 | 37875 | |||
*Power transformer three phase oil immersed electrical transformer rated voltage during 6-35kV, oil immersed transformer is most used in power plant, power grid transmission and distribution station, industry& commerce electrical substation as the electrical equipment of power transmission
1, Two windings or three windings
2, On-load or no-load voltage tapping changer
3, Natural cooling or force air or oil cooling
4, Rated capacity range 30-2500kVA
5, All parameters are for reference only; The final data will be customized according to the order.
